Condair Mk5 - Steam Installation Procedures

23
5.3 Steam installation
5.3.1 Positioning and mounting of the steam distribution pipes
The location for the steam distribution pipes should be determined at the time of dimensioning the
airconditioningsystem.Pleasenotethefollowinginstructionstoensureproperhumidicationofthe
duct air.
Calculating the humidication distance
Thewatervapor,emittingfromthesteamdistributionpipes,requiresacertaindistancetobeabsorbed
by the ambient air so that it is no longer visible as steam. This distance is referred to as humidica-
tion distance “B
N
” and serves as a basis for the determination of the minimum distances from the
upstream components in the system.
Humidication
distance B
N
Expansionandmixingzone
φ1: Incoming air humidity beforehumidication
φ2: Air humidity afterhumidication
Thecalculationofthehumidicationdistance“B
N
” is dependent on several factors. For a rough estima-
tionofthehumidicationdistance“B
N
”,thefollowingtableisuseful.Recommendedstandardvalues
listedinthistablearebasedonasupply-airtemperaturerangeof15°Cto30°C.Thevaluesgivenin
bold type only apply to steam distribution pipes 81-..., the values in brackets apply to the OptiSorp
steam distribution system.
Humidity at inlet
φ1 in %rh
Humidication distance B
N
in m
Humidity at outlet φ2 in %rh
40 50 60 70 80 90
5
0,9 (0,22) 1,1 (0,28) 1,4 (0,36) 1,8 (0,48) 2,3 (0,66) 3,5 (1,08)
10
0,8 (0,20) 1,0 (0,26) 1,3 (0,34) 1,7 (0,45) 2,2 (0,64) 3,4 (1,04)
20
0,7 (0,16) 0,9 (0,22) 1,2 (0,30) 1,5 (0,41) 2,1 (0,58) 3,2 (0,96)
30
0,5 (0,10) 0,8 (0,17) 1,0 (0,25) 1,4 (0,36) 1,9 (0,52) 2,9 (0,88)
40
− 0,5 (0,11) 0,8 (0,20) 1,2 (0,30) 1,7 (0,45) 2,7 (0,79)
50
− − 0,5 (0,13) 1,0 (0,24) 1,5 (0,38) 2,4 (0,69)
60
− − − 0,7 (0,16) 1,2 (0,30) 2,1 (0,58)
70
− − − − 0,8 (0,20) 1,7 (0,45)
Forductwidths<600mmthehumidicationdistancefortheOptiSorpsystemincreasesbyapprox.50%
φ1in%rh: Relativesupplyairhumiditypriortohumidicationatthelowestsupplyairtemperature
φ2in%rh: Relativesupplyairhumidityafterthesteamdistributionpipeatmaximumcapacity
Example
given: φ1=30%rh,φ2=70%rh
humidicationdistanceB
N
: 1,4 m (0.36mforOptiSorpsteamdistributionsystem)
Note:Ifthehumidicationdistancehastobereducedfortechnicalreasons,theamountofsteamper
basicunitmustbedividedbetweentwosteamdistributionpipesortheOptiSorp steam distribution
system must be used. If this is the case, contact your supplier.
