24
Minimum distances to be observed
To prevent the water vapor, that is emitting from the steam distributionpipe, from condensing on
downstreamsystemcomponents,aminimumdistancetothesteamdistributionpipemustbeobserved
(dependsonthehumidicationdistance“B
N
”).
before/after lter/register before/after fan, zone exit
Installation notes and dimensions
The steam distribution pipes are designed for either horizontalinstallation(ontheductwall)or,with
accessories, for verticalinstallation(intheductoor).Theoutlet orices should always point up-
wards and at right angles to the airow.
If possible, the steam distribution pipes should be installed on the pressure side of the duct (max.
duct pressure 1500 Pa).Ifthesteamdistributionpipesareinstalledonthesuctionsideoftheduct,
the maximum vacuum must not exceed 1000 Pa.
Selectalocationfortheinstallation,tailoredtosuityourduct(seethefollowingillustrations)andposition
the steam distribution pipes in the duct so that a uniform distribution of steam is achieved.
before/after constriction after expansion before bend
before branch before diffuser before control sensor
2,5xB
N
beforesubmicronparticlelter
0.5 x B
N
B
N
0.5 x B
N
B
N
B
N
5 x B
N
1.5 x B
N
*
5 cm B
N
B
N
