Condair Mk5 - Dismantling and Re-assembly Work

54
6.6.2 Dismantling and re-assembly work
Note:Thelimecollectortankmustbereplacedevery 5000 hours, or after 3 years at the latest.
Removal of the lime collector tank
Caution!Beforecommencinganydismantlingwork,thesteam-airhumidieristobetaken out
of operation as described in chapter 6.3 and rendered safe from inadvertent operation.
1. Emptythelimecollectortankviathedrainvalve.
Caution: Danger of scalding!Thewaterinthelimecollectortankmaybehot.
2. Pressthesecuringknobonbothrotationlocks.Thenrotatebothrotationlocksclockwiseandremove
thelimecollectortankdownwards,fromthebaseoftheunit.
Installation of the lime collector tank
Installationofthelimecollectortankiscarriedoutinthereversesequencetothatdetailedabovefor
removal.
Important! CheckO-ringsinthetankcouplingsleeveoftheunitandreplaceifdefective.Beforere-
mountingthelimecollectortank,greasetheO-ringsinthetankcouplingsleevewithsiliconegrease.
Important! Turntherotationlocksanticlockwiseuptothestop(bothsecuringknobsmustengage).
Important! Closedrainvalveonlimecollectortank.
