Removal and dismantling of the steam cylinder
Caution!Beforecommencinganydismantlingwork,thesteam-airhumidieristobetaken out
of operation as described in chapter 6.3 and rendered safe from inadvertent operation.
Caution! If steam has been produced shortly before discontinuing operation, the steam cylin-
der will be hot.Well-insulatedglovesshouldthereforebewornwhencarryingouttheremoval
operation.
1. Releasethefrontdoorlockingdevicesusingascrewdriver(rotate90°left)andremovethefront
doors.
2. Freetheupperhoseclampofthesteamhoseusingascrewdriverandpullthehosedownwardfrom
the steam connection.
3. Removethetwoscrews,thenpresssnap-fasteningstogetherandthenremovetheheatingcable
loomplugconnectorfromtheconnectorsocket.
4. Releasetheclampingring(steamcylinderxation).
5. Liftthesteamcylindercarefullyfromthecouplingbushandremoveittowardsthefrontoftheunit.
Caution!Setthesteamcylinderdowncarefully.
6. Loosen the steam cylinder cover clamping ring.
1 2 3
4 5 6
