Condair RM2 - Internal Humidity Sensor Setup; Controller Type and Sensor Signal Configuration

27Conguration of Condair RM control software
Congurationprocedureforhumiditycontrolviaahumiditysensorandtheinternalhumidity
controller:
1. Reset RM Control to factory settings.
(Path: Engineering > Omega Control Board > Factory Reset)
2. Reset RM Display to factory settings.
(Path: Engineering > Admin > Display > Factory Reset)
3. Set system mode to "Steam Generator".
(Pfad: Engineering > Omega Control Board > System Mode > Steam Generator)
4. Set steam humidier "Control Mode" to "rH":
(Path: Engineering > Steam Generator > Steaming Settings > Control Mode > rH)
5. Determine the controller type:
(Pfad: Engineering > Steam Generator > Steaming Settings > PID Type)
• Determine the controller type ("On/Off", "P", "PI", "PID")
6. Determine sensor signal setting:
(Pfad: Engineering > Steam humidier > Steaming Settings > Cntrl. Input Signal)
• Determine the sensor signal type ("0 - 5V", "1 - 5V", "0 - 10V", "2 - 10V", "0 - 20V", "0 - 16V",
"3 - 16V", "0 - 20mA" or "4 - 20mA")
7. Determine unit size.
(Path: Engineering > Steam humidier > Tank Settings > Capacity)
Note: The unit size can be found on the rating plate of the Condair RM under steam output.
8. Determine supply water type and cartridge size:
• Determine the supply water type ("Tap Water", "RO" or "Filter Cartridge") and the carbonate
hardness of the supply water (only if water supply type is set to " Tap Water" or "Filter Cartridge")
(Path: Service > Steam humidier > Water Supply > Type)
• Determine cartridge size (only if water supply type is set to "Filter Cartridge")
(Path: Service > Steam humidier > Filter Cartridge > Cartridge Size)
9. Set current date and time of day:
(Path: User > General)
• Set date
• Set time of day
10. Set the desired humidity setpoint:
(Path: User > Sollwert)
• Set desired humidity setpoint value in %rH
