29Conguration of Condair RM control software
6.3 Settingsinthe"Engineering"menu
Accessingthemenu"Engineering"
• Press the <Menu> button on the top right corner of the display. Then, enter the password "0000" (if
main menu is congured with password protection). The main menu appears.
Note: The password for the user menu can be modied in the "Engineering > Administration >
Password" submenu.
• Select menu item "Engineering" in the main menu.
• Enter the password ("1055") in the password entry window that appears and conrm. Then, the
"Engineering" menu appears.
Note: The content of the "Engineering" menu depends on the selected HVAC application. The following
description of the settings lists all available parameters of the "Engineering" menu.
SettingparametersMenu"Engineering"
Omega Control Board
System Mode Determining in which system mode the Condair RM Control Board should run.
– Steam Generator: Setting for the operation of the Condair RM as a pure steam generator
for HVAC applications. The steam production is controlled either by a demand signal from
an external controller or a humidity sensor signal when using the internal controller.
– Wellness: Not used with Condair RM.
Generator Kind Determining of the type of steam generation used for HVAC applications.
– None: Not used with Condair RM.
– Internal Omega: The steam is produced by a Condair RM with RM Control Board.
– Internal Reservoir: Not used with Condair RM.
– External Omega: Not used with Condair RM.
– External Analog: Not used with Condair RM.
Signaling Activation ("On") or deactivation ("Off") of the beeper for fault/warning signalisation.
Modbus Settings Setting the Modbus parameters.
– Protocessor:
– Slave Address: Determining the slave address of the Protocessor.
– Baudrate: Determining of the baud rate (4800, 9600, 19200, 38400, 57600, 115200)
– Parity: Determining of the parity (none, 1 stop bit; none, 2 stop bit; odd, 1 stop bit;
even, 1 stop bit)
– Data Format: Determining of the byte order (ABCD: big edian; BADC: big, swap;
CDAB: little, swap; DCBA: little, endi.)
– Gateway:
– Slave Address: Determining the slave address of the Gateway.
– Baudrate: Determining of the baud rate (4800, 9600, 19200, 38400, 57600, 115200)
– Parity: Determining of the parity (none, 1 stop bit; none, 2 stop bit; odd, 1 stop bit;
even, 1 stop bit)
– Data Format: Determining of the byte order (ABCD: big edian; BADC: big, swap;
CDAB: little, swap; DCBA: little, endi.)
Note: Detailed notes on Modbus communication can be found in the Modbus addendum manual.
ErrorHistoryReset Reset the list of the 50 most recent warning and error messages from the RM control electronics.
Factory Reset Resetting RM control electronics settings to factory defaults.
File System Reset Resetting the internal le system.
Note: The le system must be reset only if it does not function correctly anymore. Resetting
the le system may take several minutes (up to 5 minutes). Leave the device switched on and
wait until everything is working properly again.
