Condair RM2 - Control Settings: Safety and Keep Warm; Steam Generator and Tank Settings

30 Conguration of Condair RM control software
Control Settings
Safety Determining of the safety parameters for the humidifying operation
– Safetychain: Indicates whether the safety circuit is closed ("On") or open ("Off").
Keep Warm Determining of the keep warm functions. The keep-warm function serves to keep the water
temperature in the steam cylinder in standby mode at a certain value, so that steam can be
produced in steam operation in the shortest possible time, provided that the water has already
been heated once.
– Keep Warm Mode: Determining of the control of the keep warm operation ("Off": The keep
warm function is deactivated, "Always": The keep warm function is always activated, "Day
Timer": The keep warm function is started at a certain time of the day.
The following parameters only appear if "Day Timer" has been selected as "Keep Warm Mode".
– Keep Warm Start: Determining of the starting time (time of day) at which the keep warm
function is started.
– Keep Warm Duration: Determining of the maximum running time of the keep warm function
in hours.
Steam Generator
Steaming Settings Determining of the steam settings for the steam humidier
– Control Source: The Condair RM is always controlled locally (leave the "Control Source"
parameter at "Local").
– Input signal: Determining of the type of demand signal for the steam humidier
(0-5V, 1-5V, 0-10V, 2-10V, 0-20V, 0-16V, 3-16V, 0-20mA, 4-20mA, On/Off).
– Control Server ID: The Condair RM always uses the Server ID = 0. The setting must be
left at "0".
– Control Mode: Determining of the control mode, Demand (ext. controller) or rH (int. humidity
controller).
Note: If "Control Mode" parameter is set to "rH" , the following PID parameters are listed
additionally.
– PID Type: Determining of the control type (Off, P, PI or PID).
– PID P-Band: Determining of the proportional range in %rH for the P, PI or PID control-
ler.
– PID I-Time: Determining of the integral time in seconds for the PI or PID controller.
– PID D-Time: Determining of the differential time in seconds for the PID controller.
– Steam Demand: Current steam demand to the steam humidier in %.
Generator Shows the currently produced steam quantity by the steam humidier in %.
Level Current water level in the water tank.
Tank Settings Settings of the water tank.
– Power per Stage: Setting the power of the heating elements: 1.5 kW, 2.25 kW or 3.0 kW
– Capacity: Setting the device size 2 kg/h, 4 kg/h, 6 kg/h or 8 kg/h.
– Size: The water tank size is automatically determined by the capacity.
Safety Status indications of the safety elements of the steam humidier.
– Tank Overtemp.: Status display of the overtemperature sensor on the steam tank.
Admin
Password Determining a password for the user level (no password set ex factory).
Display Determining of the settings for the RM Display Software.
– Server ID Display: Setting the server ID of the RM Display.
– Calibrate: Performing a calibration of the RM Display.
– Factory Reset: Resetting the display electronic settings to factory defaults.
– File System Reset: Resetting the internal le system.
Note: The le system of the RM Display must be reset only if a logo must be reset or if
the le system does not function correctly anymore. Resetting the le system may take
several minutes (up to 5 minutes). During resetting, it may be that the RM Display is not
working properly and the RM Display turns white. In this case, leave the device switched
on and wait (max. 5 minutes) until everything is working properly again.
System Parameters Determining of the settings for importing and exporting data.
– Export: Export of data to the internal le system ("SpaExportSettings.json").
– Import: Import of data from the internal le system ("SpaExportSettings.json").
