31Conguration of Condair RM control software
Menu Tree
Cabin 1 Settings not used with Condair RM
Cabin 2 Settings not used with Condair RM
Steam Generator 1 Determining whether the settings of the steam generator 1 should be displayed on the RM Display.
– Enable: Display enabled ("On") or disabled ("Off").
– Server ID: Determining of the CAN BUS ID of the Condair RM control board.
Steam Generator 2 Settings not used with Condair RM
Diagnostic Determining which control boards should be displayed in diagnostic mode on the RM Display.
– Server ID 0: Display enabled ("On") or disabled ("Off").
– Server ID 1 to Server ID 7: Not used with Condair RM.
IP Settings
HostNameSufx Determining of the host name sufx.
DHCPMode Determining whether DHCP mode should be used ("On") or not ("Off").
IP Address Determining of the static IP address of the Condair RM.
Subnet Mask Determining of the subnet mask for IP communication.
Gateway Determining of the Gateway IP address of the Condair RM.
DNS Primary Determining of the IP Address of the primary domain name server (DNS).
The IP address for the primary domain name server is used when DHCP mode is off.
DNS Secondary Determining of the IP Address of the secondary domain name server (DNS).
The IP address for the secondary domain name server is used when DHCP mode is off.
Diag. Board ID 0
Note: Only the boards that were selected in the menu tree appear under Diagnostics.
Output Sensor Setup Diagnostics of the settings for the sensor inputs.
– Demand Select: Switching between current and voltage measurement.
– Humidity Select: Not used with Condair RM.
– Temp. Control: Not used with Condair RM.
– Temp Gain: Not used with Condair RM.
– Bench Temp. Control: Not used with Condair RM.
– Bench Temp. Gain: Not used with Condair RM.
Output Relay Diagnostics of the relay outputs.
– Sec. Contactor: Switching the safety contactor on and off.
– Inlet Valve: Switching the inlet valve of the Condair RM on and off.
– Relay Drain: Switching the relay of the drain pump of the Condair RM on and off.
– Relay Fan 1: Not used with Condair RM.
– Relay Fan 2: Not used with Condair RM.
– Relay 8: Switching the additional relay 8 on and off.
– Relay 9: Not used with Condair RM.
– Relay Error: Switching the error relay on and off (Err Out).
– Relay Light 1: Not used with Condair RM.
– Relay Light 2: Not used with Condair RM.
– Relay Pump 1: Not used with Condair RM.
– Relay Pump 2: Not used with Condair RM.
OutputHeat Diagnostic of the heating circuits.
– Heat 1: Switching the heating circuit 1 on and off.
– Heat 2: Switching the heating circuit 2 on and off.
– Heat 3 to Heat 5: Not used with Condair RM..
Signaling Turning the beeper on and off.
Output Analog Diagnostic of the analog outputs.
– Led Red: Control of the red LED of the Condair RM (fault).
– Led Green: Control of the green LED of the Condair RM (steam production).
– Demand: Control of the demand to the external steam humidier.
– Reserve: Control of the reserve output
Status Relay Indication of the current state of the relay.
– Status Valve: "On" (switched on), "Off" (switched off).
– Status Sec Contactor: "On" (switched on), "Off" (switched off).
