32 Conguration of Condair RM control software
StatusHeat Indication of the current state of the heating circuits.
– Heat 1: "On" (switched on), "Off" (switched off).
– Heat 2: "On" (switched on), "Off" (switched off).
– Heat 3 to Heat 5: Not used with Condair RM.
Input Digital Indication of the current state of the digital inputs.
– Cartridge Reset: "On" (reset button pressed), "Off" (reset button not pressed).
– Cabin Overtemp.: "On" (no overtemperature), "Off" (overtemperature switch has triggered).
– Low Water: "On" (water level OK), "Off" (water level too low).
– Level 1: "On" (water level at level 1), "Off" (water level below level 1).
– Level 2: "On" (water level at level 2), "Off" (water level below level 2).
– Level 3: "On" (water level at level 3), "Off" (water level below level 3).
– On/Off: Not used with Condair RM.
– Door: Not used with Condair RM).
– Light 1: Not used with Condair RM.
– Light 2: Not used with Condair RM.
– Safetychain: "On" (Safety chain closed), "Off" (Safety chain open)
– Tank Overtemp.: "On" (no overtemperature in the steam tank), "Off" (overtemperature
switch for steam tank has triggered).
– Hardware Option SPA Control: Shows he hardware option of the Condair RM.
Input Analog Indication of the current state of the analog inputs.
– 24 V Local: Current voltage of the internal 24 V power supply.
– 5 V Local: Current voltage of the internal 5 V power supply.
– 24 V Extern: Current voltage of the external 24 V power supply.
– 5 V Extern: Current voltage of the external 5 V power supply.
– Demand: Current voltage value of the demand signal.
– Temperature: Not used with Condair RM.
– Bench Temp.: Not used with Condair RM.
– Humidity: Not used with Condair RM.
– Reserve: Current voltage value of the reserve input.
