24 Conguration of Condair RM control software
6 CongurationofCondairRMcontrolsoftware
The Condair RM control software is congured via the "Service" and the "Engineering" menu. chapter
6.1 describes the conguration processes for the respective applications. In chapter 6.2 and chapter
6.3 you will nd an overview of the setting parameters of the "Service" and the "Engineering" menu.
6.1 Congurationprocedures
6.1.1 Congurationprocedureforhumiditycontrolviaanexternalhumiditycontroller
External humidity controller installed
in the supply or return duct
Condair RM with
external controller enabled
Air ow monitor
Maximum humidistat
Return Duct
Supply duct
Fig. 5: System layout for operating the Condair RM with a demand signal from an external humidity
controller
