Condair RM2 - Removal and Installation of the Inlet Valve

45Maintenance
7.4.5 Removal and installation of the inlet valve
For removing the inlet valve the steam tank must not be removed.
3
5
1
2
4
Fig. 11: Removal of the inlet valve
1. Detach electric cables (polarity of the cables must not be observed).
2. Release hose clamp and remove the hose from the connector.
3. Undo external water supply pipe and remove.
4. Undo the two screws with Phillips screwdriver, then remove the inlet valve.
5. Remove strainer insert with pointed pliers.
The installation of the inlet valve follows the reverse sequence of the removal. Before installing the valve
make sure the strainer insert is installed in the inlet valve.
