Condair RM2 - 10 Product Specification; Performance Data; Fuses F6 Voltage Supply; Operating Data

66 Product specication
10 Productspecication
10.1 Performancedata/Fuses"F6"voltagesupply
Condair RM
230V/1~/50...60Hz 400V/3~/50...60Hz
Max.steamcapacity in kg/h P
N
max.
in kW I
N
max.
in A Cable cross section AL min. in mm
2
Fuses"F5"
in A, quick acting (gR)
Max.steamcapacity in kg/h PNmax. in kW INmax. in A Cable cross section AL min. in mm
2
Fuses"F5"
in A, quick acting (gR)
2 2.0 2.0 8.7 1.5 10 –– –– –– –– ––
4 4.0 3.5 15.3 2.5 16 –– –– –– –– ––
6 6.0 5.0 21.8 6.0 25 6.0 5.0 12.0 2.5 16
8
8.0 6.5 28.3 6.0 32
8.0 6.5 15.3 2.5 16
10.2 Operating data
Condair RM
2 4 6 8
Supply voltage 230 V/1~/50...60 Hz
--- 400 V/3~/50...60 Hz
Number of heating elements 1 2 2 2
Max. steam capacity 2 kg/h 4 kg/h 6 kg/h 8 kg/h
Power heating elements 1.5 kW 1.5 kW 2.25 kW 3.0 kW
Admissible control signals 0-5 V, 1-5 V, 0-10 V, 2-10 V, 0-20 V, 0-16 V, 3-16 V,
0-20 mA, 4-20 mA, On-Off
Admissible temperature sensors PT100, PT1000, KTY
Admissible ambient temperature 1...40 °C
Admissible ambient humidity 1...75 %rh (non-condensing)
Admissible water supply temperature 1...40 °C
Admissible water supply pressure 1…10 bar
Water drain temperature max 90 °C
Protection class IP20
