55Fault elimination
8.2 Fault indication
Malfunctions during operation detected by the control software are indicated by the yellow illuminated
LED (warning present or maintenance due) or the red illuminated LED (fault present) above the unit
switch and by the yellow or red warning triangle in the upper left corner of the display.
Warning (maintenance indication)
Warnings and/or a due maintenance are indicated by the yellow warning triangle
in the home screen and the yellow illuminated LED above the unit switch. The
Condair RM continues operation. Depending on the type of warning, certain
operational restrictions may occur.
Fault
Operational states where further operation is limited or not possible, or where
further operation would damage the system are indicated by the red warning
triangle in the home screen and the red illuminated LED above the unit switch.
Depending on the type of fault the steam production is stopped or the Condair
RM continues normal operation.
By pressing on the warning triangle the error list is shown with all active warning and fault messages. By
pressing on the corresponding Warning or Fault entry additional information regarding the malfunction
are displayed (see display on the far-right).
Fault 20
Fault 22
Warning 54
Error List
Safety Loop
2018-11-06 10:15:09
ServiceId: 0, ModuleId: 10
External safety chain is open.
Fault 20
