19 | P a g e
1
st
press displays Activity screen
2
nd
press displays the Routing screen
3
rd
press (optionally – set in settings) displays the MIDI MON screen
4
th
press brings you back to the screen you were on.
The second “fast navigation” function for pressing the Encoder button is for the modifiers. If you are on
the Router screen and the tab-stop is on one of the MOD (modifier) boxes, pressing the Encoder button
will jump you to the MOD (modifier) screen for editing. Press again and it returns you to the Router
screen.
Shift Button
Here is a list of the Shift button functions:
!!! USEFUL FOR NAVIGATION !!!
Shift + Encoder rotate – speeds up the inc/dec of the tab-stop value
Shift + Encoder button press – PANIC, sends MIDI Note-off messages to routed out-Ports.
Shift + Encoder (long) button press – BIG PANIC, sends MIDI Note-off messages to all out-Ports.
Shift + in-port or out-port button press – shows that port’s label name on the Routing screen banner
without making any routing selection changes.
Shift + “Y” button press – toggles on/off the LED light show
Shift + Enter button press (Routing Page only) – clears all filters and modifier boxes
Stand-By Button
Holding the green Stand-by button for ~2 sec will put the MRCC in Stand-by mode. This mode turns off
the LEDs, the OLED screen, MRCC Clock and Arps, stops all MIDI message traffic, and optionally (menu
setting) powers down all USB devices plugged into the HOST ports. To resume, press the green Stand-by
button again.
Briefly pressing the Stand-by button will move the tab-stop to the top level button menu.
Holding the Stand-by button while booting (hold until you see the boot menu) will reset the MRCC
settings and erases all the Preset files on the SD Card.
MRCC Remote Routing Button “Y”
The “Y” button enables routing to MRCC Remote products or to a second MRCC*. In order to route to a
remote device press and hold the “Y” button while selecting a remote out-port.
*More on the MRCC Remote”X” Devices in Appendix A
