B. MIDI Implementation: CC (Control Change) & Program Change
Go to the Setting Page 1 in the MRCC to set which Port and Channel to receive CC and Program Change messages
on.
CC (Dec)
CC
(Hex)
Target
Range
Range Description
21-27
Arpeggiator
Receives CC messages on the port & channel the arpeggiator is
setup to listen on
21
15
Enable
0-127
Off < 63 < On
22
16
Arp Latch
0-127
Off < 63 < On
23
17
Set Arp Mode
0-5
0-Up, 1-Down, 2-PingPong inclusive, 3-PingPong exclusive, 4-Order
Played , 5-Shuffle, (6-Random - TBD)
24
18
Set Arp Octave
1-3
Plays note in 1-1 octave, 2-2 octaves, 3-3 octaves
25
19
Set Arp Gate
0-5
0-10%, 1-25%, 2-50%, 3-75%, 4-90%, 5-Random %
26
1A
Set Arp Rhythm
0-14
0-14 map to rhythms A - L
27
1B
Set Arp Clk Div
0-9
0-4 bars, 1-2bars, 2-1bar, 3-3/bar, 4-1/2note, 5-triplet ½ note, 6-1/4
note, 7-triplet 1/4, 8-1/8 note, 9-triplet 1/8 note
30-32
MRCC General
Receives CC messages on the port & channel defined in the Setting
Menu #1 Port and Channel parameters.
30
1E
MRCC Clock
Enable
0-127
Off < 63 <= On
31
1F
MRCC Clock Beats
per Min (BPM)
5-120
x2 value -> 10 to 240 BPM
ex. 5=10BPM, 50=100BPM, 75=150BPM
32
20
MRCC Clock Pulses
per Quarter Note
(PPQ) for CV
analog output
0-3
0-1 PPQ, 1-2 PPQ, 2-4 PPQ, 3-24 PPQ
Program
Change
0-127
Loads the Preset 0 (Default) to 127 into the MRCC
