Physical Input/Output:
• 5x MIDI 5-Pin DIN Inputs
• 4x MIDI 1/8” TRS Inputs (MIDI Type A and B)
• 4x USB 2.0 (High Speed, 480Mbit) Type A Host Inputs/Outputs
• 1x USB 2.0 (Full Speed, 12Mbit) Type B Device Inputs/Outputs
• 10x MIDI 5-Pin DIN Outputs
• 4x MIDI 1/8” TRS Outputs (MIDI Type A and B)
• 1x MRCC Remote (RJ45) connector – NOT ETHERNET. Only for use with Conductive
Labs accessories.
• 1x CV Clock Output 1/8” TS jack (requires a TS mono cable, not TRS stereo). +5V
(default) or +12V configurable.
• 1x MicroSD Card slot (behind left panel).
• 1x USB-PD Type C power connector (power only, no USB data)
