6System Update and Programming Service & Maintenance Manual
34
5100614_CFD5000 T - CM4.3_Service & Maintenance Manual_T_EN_2020_E
NOTE!
The system will use the latest version of the file (with the last date and time).
The configuration file can be uploaded using an approved USB memory stick
(available from an authorised dealer).
CAUTION!
Do not remove the USB memory stick until the upload is finished.
1 Connect the USB memory stick to the USB port in the control module.
2 Choose Menu » 6 Service menu » 6 Configuration » 2 Load configuration from USB
Memory.
3 A list of the available configuration files on the USB memory stick will be presented.
Supported files are “.ccp”, “espa.bin”, “modbus.bin” and
“modbus1.bin”-“modbus30.bin”.
Choose the appropriate configuration file from the list and press OK.
4 The new configuration file is uploaded to the fire detection system. The old
configuration file is automatically renamed by the system (as a back-up file with the file
extension “.bak”) and saved on the USB memory stick.
5 Disconnect the USB memory stick.
6 To synchronise the configuration files between the control modules and repeaters in the
EN54 system choose Menu » 6 Service menu » 6 Configuration » 6 Synchronise system
configuration.
7 Reboot the system by choosing Menu » 6 Service menu » 6 Configuration » 7 Reboot
system (this module excluded).
There will be a 15 seconds delay before the system restarts.
8 Update the system with the new configuration file by choosing Menu » 6 Service menu
» 6 Configuration » 1 Reload Configuration/Reboot this module.
9 The Control M 4.3 restarts and loads the new configuration file.
10 To change the active configuration of CS-Safety M and CS-Loop M modules in the
system choose Menu » 6 Service menu » 6 Configuration » 8 Synchronise the
CS-modules.
The control module will synchronise and then restart the CS-modules.
6.2 Upgrade BIOS from a USB Memory Stick
This instruction describes how to upgrade BIOS in a CFD5000 system using a
USB memory stick.
Follow all steps below:
A. Prepare the USB memory stick
B. Upgrade BIOS in a Control M 4.3, Repeater M 4.3 or Control M 2.2
Prerequisites
•
Laptop running Windows 2000/XP/Vista/7/8
