Service & Maintenance Manual 7Fault Codes
5100614_CFD5000 T - CM4.3_Service & Maintenance Manual_T_EN_2020_E
37
7 Fault Codes
NOTE!
Any fault codes that are generated may depend on the system configuration.
7.1 Fault Codes for CFD5000
WARNING!
In case of remedy “replace the unit” or “replace the module” – this has to be carried
out as soon as possible in order to secure the functionality of the fire detection
system.
WARNING!
If an internal hardware or software fault has occurred it has to be restored as prompt
as possible in order to secure the functionality of the complete fire detection system.
The detection of a dangerous fault shall result in either:
1. a specified action to achieve or maintain a safe state; or
2. the repair of the faulty system within the mean repair time (MRT). During this time the
continuing safety shall be ensured by additional measures and constraints. The safety
integrity provided by these measures and constraints shall be at least equal to the safety
integrity provided by the FDS in the absence of any faults.
Listed in the table below are all fault codes generated by system modules
1
and loop units
2
,
their causes, and how an operator with knowledge of the system can classify and solve the
problem.
A fault generated by a system module is often identified as:
“CENTRAL nn Unit type nn Fault description, FAULT nnn”
A loop unit fault is often identified as:
“ZONE nn Unit type nn Fault description, FAULT nnn”
Hint!
Instructions for troubleshooting and replacement can be found in the Installation &
Commissioning manual
3
or the Service & Maintenance manual
4
.
1) Central components and control/repeater panels.
2) Units connected to the loop-line, e.g. detectors and manual call points.
3) References to the Installation & Commissioning manual are indicated in the remedy column with the symbol *.
4) References to the Service & Maintenance manual are indicated in the remedy column with the symbols **.
