Consilium CFD5000 T / CM4.3 - Appendix B; System Modules & Connection Example

Service & Maintenance Manual 8Appendix A
5100614_CFD5000 T - CM4.3_Service & Maintenance Manual_T_EN_2020_E
53
•
Press 1 to send a list with details for the selected central to a connected printer.
•
Press 2 to open the module list (similar to Modules main screen described in
section Modules, Submenu 3, page 53).
8.1.4 Modules, Submenu 3
Modules main screen
The Module screen lists the modules in the system:
CENTRAL x x is the number of the central where the module is placed
MODULE name x name is the module type and x is the address of the
module
(MODULE OK / BOOTING /
CONFIG NOT FOUND)
Module status
•
Press OK to monitor details about the selected module. (See OK=Details
below.)
•
Press 0 to disable the selected module; all I/Os on the module will be disabled
and the fault associated with the module will disappear from the fault list.
•
Press 1 to send a list with modules to a connected printer.
•
Press 2 to monitor and manipulate the inputs of the selected module. (See
2=Inputs below.)
•
Press 3 to monitor and manipulate the outputs of the selected module. (See
3=Outputs below.)
•
Press 4 to monitor the loop of the selected module (if the module is a loop
module). The loop screens are explained in section Loops, Submenu 5, page
55.
OK=Details screen
Details about system module:
HW Hardware version
SW Software version
Timestamp Config Time and date of configuration
No of inputs/outputs Number of inputs and outputs on the module
Communication errors Number of reported communication errors for loop
modules in the last 65535 tries
•
Press OK to go back to list view.
•
Press 0 to disable the selected module; all I/Os on the module will be disabled
and the fault associated with the module will disappear from the fault list.
•
Press 1 to send a list with details for the selected module to a connected printer.
•
Press 2 to monitor and manipulate the inputs of the selected module. (See
2=Inputs below.)
