Control Techniques Mentor MP User Manual

Menu 8
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
118 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
Table 5-7 Digital inputs / outputs
OFF (0) = Terminal inactive
ON (1) = Terminal active
Terminal + type
I/O state Invert Source / destination Output select
Pr Pr Default Pr Default Pr Default
T24 input / output 1
Pr 8.01
= {in05, 0.85}
Pr 8.11 0Pr 8.21 Pr 10.06 - At speed Pr 8.31 1
T25 input / output 2
Pr 8.02
= {in06, 0.86}
Pr 8.12 0Pr 8.22 Pr 10.33 - Drive reset Pr 8.32 0
T26 input / output 3
Pr 8.03
= {in07, 0.87}
Pr 8.13 0Pr 8.23 Pr 6.30 - Run forward Pr 8.33 0
T27 input 4
Pr 8.04
= {in08, 0.88}
Pr 8.14 0Pr 8.24 Pr 6.32 - Run reverse
T28 input 5
Pr 8.05
= {in09, 0.89}
Pr 8.15 0Pr 8.25 Pr 1.41 - Local/remote
T29 input 6
Pr 8.06
= {in10, 0.90}
Pr 8.16 0Pr 8.26 Pr 6.31 - Jog
T51, T52, T53 relay state Pr 8.07 Pr 8.17 0Pr 8.27 Pr 10.01 - Drive OK
T31 Enable Pr 8.09
T61, T62, T63 relay state Pr 8.40 Pr 8.50 0Pr 8.60 Pr 6.55 - Contactor enable
Start button Pr 8.41 Pr 8.61 Pr 0.00
Forward / Reverse button Pr 8.42
Pr 8.52
(toggle)
0Pr 8.62 Pr 0.00
24 V Input Pr 8.48
8.01
{in05, 0.85}
T24 digital I/O 1 state
8.02
{in06, 0.86}
T25 digital I/O 2 state
8.03
{in07, 0.87}
T26 digital I/O 3 state
8.04
{in08, 0.88}
T27 digital input 4 state
8.05
{in09, 0.89}
T28 digital input 5 state
8.06
{in10, 0.90}
T29 digital input 6 state
8.07 T51, T52, T53 relay state
8.09 T31 drive enable state
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11
11
Default See Table 5-7
Update rate 4 ms write
