Control Techniques Mentor MP User Manual

Menu 9
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
126 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
When this bit is set to 0 the motorized pot output is limited to positive values only (i.e. 0 to 100.0 %). Setting it to 1 allows negative outputs
(i.e. ±100.0 %).
This parameter defines the time taken for the motorized pot function to ramp from 0 to 100.0 %. Twice this time will be taken to adjust the output from
-100.0 % to +100.0 %.
This parameter can be used to restrict the output of the motorized pot to operate over a reduced range so that it can be used as a trim, for example.
Pr 9.21 Mode Comments
0 Zero at power-up
Reset to zero at each power-up.
Up, down and reset are active at all times.
1 Last value at power-up
Set to value at power-down when drive powered-up.
Up, down and reset are active at all times.
2
Zero at power-up and only
change when drive running
Reset to zero at each power-up.
Up and down are only active when the drive is running (i.e.
drive active). Reset is active at all times.
3
Last value at power-up and
only change when drive
running
Set to value at power-down when drive powered-up.
Up and down are only active when the drive is running (i.e.
drive active). Reset is active at all times.
9.22 Motorized pot bipolar select
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
9.23 Motorized pot rate
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 250 s
Default 20
Update rate Background read
9.24 Motorized pot scale factor
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate 4 ms x number of menu 9 or 12 functions active read
9.25 Motorized pot destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 0.00
Update rate Read on reset
9.26 Motorized pot up
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
