Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 9
Mentor MP Advanced User Guide 127
Issue Number: 4 www.controltechniques.com
These three bits control the motorized pot. The up and down inputs increase and decrease the output at the programmed rate respectively. If both up
and down are active together the up function dominates and the output increases. If the reset input is one, the motorized pot output is reset and held
at 0.0 %.
9.27 Motorized pot down
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
9.28 Motorized pot reset
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
9.29 Binary sum ones input
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
9.30 Binary sum twos input
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
9.31 Binary sum fours input
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
9.32 Binary sum output
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 0 to 255
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active write
9.33 Binary sum destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 0.00
Update rate Read on reset
