The value written to the destination parameter is (PID controller output x scaling) + PID main reference.
When this parameter is set to 0 the integrator operates normally. Setting this parameter to 1 will cause the integrator value to be held. Setting this
parameter does not prevent the integrator from being reset to zero if the PID controller is disabled.
See Pr 14.13 and Pr 14.14.
14.15 PID scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate 4 ms read
14.16 PID destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 0.00
Update rate Read on reset
14.17 PID hold integrator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms read
14.18 PID symmetrical limit enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
14.19 PID main reference
Coding Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1
Range ±100.00 %
Update rate 4 ms write
14.20 PID reference
Coding Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1
Range ±100.00 %
Update rate 4 ms write
14.21 PID feedback
Coding Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1
Range ±100.00 %
Update rate 4 ms write
