Menu 1
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
24 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
See Pr 1.09 on page 26.
Reference used for jogging. See section 5.7 Menu 6: Sequencer and clock on page 97 for details on when the jog mode can be activated. The jog
reference can be used for relative jogging in digital lock mode (see section 5.14 Menu 13: Position control on page 172).
See also Pr 1.07 overleaf.
1.01
{di01, 0.36}
Speed reference selected
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1 1
Range ±MAX_SPEED_REF rpm
Update rate 4 ms write
1.02 Pre-skip filter reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1 1
Range ±MAX_SPEED_REF rpm
Update rate 4 ms write
1.03
{di02, 0.37}
Pre-ramp reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1 1
Range ±MAX_SPEED_REF rpm
Update rate 4 ms write
1.04 Reference offset
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range ±10,000.0 rpm
Default 0.0
Update rate
Background read when precision reference is active
4 ms write otherwise
1.05 Jog reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 to 1,000.0 rpm
Default 0.0
Update rate 4 ms read
1.06
{SE02, 0.23}
Maximum reference clamp
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range SPEED_LIMIT_MAX rpm
Default 1000.0
Second motor
parameter
Pr 21.01
Update rate Background read
