*The range shown for Pr 1.07 shows the range used for scaling purposes (i.e. for routing to an analog output etc). Further range restrictions are
applied as given below.
The effects of the reference clamps (Pr 1.06 {SE02, 0.23} and 1.07 {SE01, 0.22}), the negative minimum clamp enable (Pr 1.08) and the bipolar
reference enable parameters are defined below.
The variable maximum limit for reference parameters, MAX_SPEED_REF, is defined as:
If Pr 1.08 = 0: MAX_SPEED_REF = Pr 1.06 {SE02, 0.23}
If Pr 1.08=1: MAX_SPEED_REF is Pr 1.06 {SE02, 0.23} or -Pr 1.07 {SE01, 0.22} whichever is the largest
(If the second motor map is selected Pr 21.01 is used instead of Pr 1.06 {SE02, 0.23} and Pr 21.02 instead of Pr 1.07 {SE01, 0.22})
1.07
{SE01, 0.22}
Minimum reference clamp
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 111
Range ±SPEED_LIMIT_MAX rpm*
Default 0.0
Second motor
parameter
Pr 21.02
Update rate Background read
Pr 1.08
(Neg min ref enable)
Pr 1.10
(Bipolar mode enable)
Range
0 0 0 to Pr 1.06 {SE02, 0.23}
01 0
1 0 -SPEED_LIMIT_MAX to 0 rpm
1 1 -SPEED_LIMIT_MAX to 0 rpm
1.08 Negative minimum reference clamp enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
