Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 3
Mentor MP Advanced User Guide 45
Issue Number: 4 www.controltechniques.com
If the speed feedback (Pr 3.02 {di05, 0.40}) exceeds this level in either direction an overspeed trip is produced. If this parameter is set to zero, the
overspeed threshold is automatically set to 1.2 x SPEED_MAX.
"At speed" flag (Pr 10.06) is set if the speed feedback (Pr 3.02 {di05, 0.40}) is on the boundaries or within the at speed window. Flags Pr 10.07 and Pr
10.05 are set if the reference is above or below the window respectively.
If Pr 3.09 = 0 reference window mode is used and the "at speed" condition is true if
(|Pr 1.03 {di02, 0.37}| - Pr 3.06) ≤ |Pr 3.02 {di05, 0.40}| ≤ (|Pr 1.03 {di02, 0.37}| + Pr 3.07)
(If the lower limit is less than zero then zero is used as the lower limit.)
If Pr 3.09 = 1 absolute window mode is used and the "at speed" condition is true if
Pr 3.06 ≤ |Pr 3.02 {di05, 0.40}| ≤ Pr 3.07
See the description under Pr 3.16.
See the description under Pr 3.16
3.08 Overspeed threshold
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 10,000 rpm
Default 0
Update rate Background read
3.09 Absolute “at speed” select
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
3.10
{SP01, 0.61}
(Kp1) Speed controller proportional gains
(Kp2)
3.13
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
4111
Range 0.0000 to 6.5535 (1 / (rad/s))
Default 0.0300
Second motor
parameter
Pr 21.17 (3.10)
Update rate Background read
3.11
{SP02, 0.62}
(Ki1) Speed controller integral gains
(Ki2)
3.14
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111
Range 0.00 to 655.35 (s / (rad/s))
Default 0.10
Second motor
parameter
Pr 21.18 (3.11)
Update rate Background read
