Manuale di Istruzione
Instruction Manual
23/08/2018 Rev.1 EN
110
6.1 System (Hidden) menu
This menu allows setting a number of functioning parameters of the system and
performing procedures reserved to CONTROLS authorized service organisation.
WARNING:
Refer to qualified service organization authorized by CONTROLS to carry out the service
maintenance actions described in the chapter “Diagnostic and Troubleshooting”.
CONTROLS has not to be held responsible for damages to the equipment and/or injuries
to personnel in case the above is not strictly followed.
To access the SYSTEM (HIDDEN) MENU:
1. Turn OFF the unit;
2. Press and hold the key, turn ON the unit via its MAIN
SWITCH on the rear panel: after a few seconds, the unit will show
following screen;
Fig. 6-1
3. Hold the key for another 2 seconds then release it, the system
will ask for a password;
Fig. 6-2
To Next Page
