Controls WIZARD 2 50-C92AXX User Manual

Manuale di Istruzioni
Instruction Manual
Rev.1 EN 23/08/2018
65
4.2.2 ARCHIVE menu
Saved files are stored in an USB memory stick to be connected on the dedicated port
located on the rear panel of the WIZARD 2. The number of tests that can be stored
depends on the capacity of the memory stick.
On the MAIN MENU select the option ARCHIVE and press the key to access
the ARCHIVE MANAGER screen.
Fig. 4-11
Use the to select the desired option and the key to proceed.
Selecting the VIEW SINGLE RECORD option, the system will show the last test stored
as follows.
Fig. 4-12
Use the keys to scroll through the different stored tests.
NOTE:
Access to the VIEW SINGLE RECORD screen is not possible if the memory stick is not
connected into the USB port of the control unit or there are not test stored into it.
Press the key to return to the ARCHIVE menu.
Select the other 2 options to print all records on the internal printer (optional device) or to
send all data to the computer via the LAN port. After activating the action with the
key, the system will require a confirmation before proceeding.
The command to erase the archive is in the OPTIONS menu (see chapter 4.2.3.3).


Controls WIZARD 2 50-C92AXX Specifications

General

Brand	Controls
Model	WIZARD 2 50-C92AXX
Category	Laboratory Equipment
Language	English
