Manuale di Istruzioni
Instruction Manual
Rev.1 EN 23/08/2018
57
4.1 Switching on the equipment
1. Once all the connections have been made correctly and the USB memory stick has
been inserted into the relevant port on the rear panel (in case data storage into the
memory is required) switch ON the unit via the power switch on the rear panel;
Fig. 4-1
WARNING:
Do not use the USB port to re-charge batteries of external devices (e.g mobile phone,
audio-video players, etc.). It is also mandatory to connect/disconnect the USB memory
stick with the unit OFF.
CONTROLS will not be held responsible for damages to persons and/or properties in
case these instructions are not strictly followed.
The green light of the printer (optional) will lit, the display will first show a start up
screen and after 5 seconds a screen with the status of the system interfaces;
Fig. 4-2
2. Follow two information screens with the configuration and status of the device
(press the key to access the second of these screens);
Fig. 4-3
3. Press again to proceed and access the MAIN MENU.
Mains switch
