3.1 Shipment
The equipment is normally shipped in a wooden crate having the following dimensions
and gross weight depending on the model:
Models Gross weight
Overall dimensions
(L x D x H)
Minimum
fork lift
length
50-C92A0X with
pedestal
386 Kg 1150x850x1570 mm
1500 mm
without
pedestal
286 Kg 1000x700x1250 mm
50-C92A1X with
pedestal
386 Kg 1150x850x1570 mm
1500 mm
without
pedestal
286 Kg 1000x700x1250 mm
50-C92A2X with
pedestal
440 Kg 1150x850x1570 mm
1500 mm
without
pedestal
350 Kg 1250x850x1400 mm
Use a proper fork lift with minimum fork length as above indicated to raise and move the
wooden crate (see figure below).
Fig. 3-1 100 Kg wooden crate
