Manuale di Istruzioni
Instruction Manual
Rev.1 EN 23/08/2018
27
2.1 Frames
High rigidity solid one piece steel frame. Spherical seat allows free alignment at the
initial contact with the specimen. There is a 600 kN frame, model code 50-C92A0X and a
500 kN frame, model code 50-C92A1X.
There is also a second testing chamber with a 15 kN frame, only in model code 50-
C92A2X.
2.2 Compression platens
165 mm dia., surface hardness 55 HRC, flatness tolerance 0.02 mm.
2.3 Hydraulic power unit
Dual stage pump: low pressure/high delivery for fast piston approach and high
pressure/low volume for loading. Fitted with special hand operated pressure-compensated
proportional valve for the manual preset of load rate.
2.4 WIZARD 2 display unit
For load measurement. The unit feature: set up of specimen dimensions; easy preload
zeroing; real time display of load and stress; real time display of applied load rate by
symbols for easy adjustment; digital calibration; effective resolution 1/65000; LAN port
for PC connection.
The WIZARD 2 system can be factory fitted with an internal serial printer (50-
C10A/PR).
