Controls WIZARD 2 50-C92AXX User Manual

Manuale di Istruzione
Instruction Manual
23/08/2018 Rev.1 EN
26
Fig. 2-3 – Machine with 2 frames (600 kN and 15 kN), code 50-C92A2X
Ref. Description
1
Load cell on 15 kN frame
2
Upper platen
s
with spherical seat
s
3
Front guard
4
Lower platen
5
Piston travel indicator
6
Control unit
7
Flow control valve
8
AC motor dual
stage h
ydraulic pump
with MOTOR ON switch
9
EMERGENCY BUTTON
10
ON/OFF Hydraulic valve
11
Frame selector
lever (lever UP=Frame #1, lever DOWN=Frame #2)
12
Speed selector (rapid approach, test speed)
13
Oil tank
1
3
2
4
6
8
9
7
5
10
13
11
12
