Manuale di Istruzione

Instruction Manual

23/08/2018 Rev.1 EN

4.3.1 Selection of the frame to use for 50-C92A2X machine

Depending on the type of test to perform, select the relevant frame by means of the frame

selector lever here after shown:

• Lever UP to select Frame #1;

• Lever DOWN to select Frame #2.

Fig. 4-20

Frame selector

lever
