Controls WIZARD 2 50-C92AXX User Manual

Manuale di Istruzione
Instruction Manual
23/08/2018 Rev.1 EN
24
2. DESCRIPTION
Refer to the following figures for main components identification.
Fig. 2-1 Machine with 600 kN frame, code 50-C92A0X
Ref. Description
1
Upper platen with spherical seat
2
Front guard
3
Lower platen
4
Piston
travel indicator
5
Control unit
6
Flow control valve
7
AC motor dual stage h
ydraulic pump
with MOTOR ON switch
8
EMERGENCY BUTTON
9
ON/OFF Hydraulic valve
10
Speed selector (rapid approach, test speed)
11
Oil tank
11
1
6
9
5
8
10
2
3
4
7
