2.8 Technical specifications
Main characteristics
Product
50-C92AXX WIZARD 2 Compression and Flexural machines, multipurpose
models
Manufacturer
CONTROLS Liscate (MI) Italy
Type
Single Chamber
Single Chamber
Double Chamber
Models
50
-
C92A0
X
C92A
1
X
C92A2
X
Product code 230VAC version 50-60
Hz, 1 ph
50-C92A02 50-C92A12 50-C92A22
Product code 220VAC version 60
Hz, 1 ph
50-C92A03 50-C92A13 50-C92A23
Product code 110VAC version 60
Hz, 1 ph
50-C92A04 50-C92A14 50-C92A24
Capacity [kN]
600
500
600/15
Load measurement sensor Pressure transducer Load cell Pressure
transducer/Load cell
Class 1 range 60 kN ÷ 600 kN 50 kN ÷ 500 kN 60 kN ÷ 600 kN
1.5 kN ÷ 15 kN
With
50
-
C0050/CAL2
15 kN ÷ 600 kN
-
15 kN ÷ 600 kN
With
50
-
C0050/CAL5
-
-
0.75 kN ÷ 15 kN
Wit
h
50
-
C0050/CAL
-
5 kN ÷ 500 kN
-
Single phase line voltage
110 VAC/220 VAC/230 VAC +10%, -10%
Frequency 50-60 Hz/60 Hz
Power 750 W
Method of power entry Power cable with plug
Computer connection LAN port
Platens
dia. [mm]
165
x30
165
x30
165
x30
Hardne
ss [HRC]
55
55
55
Flatness [mm]
0.02
0.02
0.02/0.02
Ram travel
[
mm
]
50
50
50/30
Max vertical daylight
[mm]*
345 240 345/205
Horizontal daylight [mm]
265
265
265
Fast approach speed 40 mm/min approx.
Max. working pressure 650 bars
Oil output at max. pressure 0.3 l/min approx.
Oil tank capacity (approx.) 6 liters
Acoustic pressure < 70db(A)
Overall dimensions (lxdxh)
[mm]
See next figures
Net weight approx. (with pedestal)
kg:
286 286 340
Net weight approx. (without
pedestal)
kg:
226 226 280
[*] To be adjusted using the suitable distance pieces.
