Controls WIZARD 2 50-C92AXX User Manual

Manuale di Istruzioni
Instruction Manual
Rev.1 EN 23/08/2018
33
Main characteristics
Model 50- C13A02
C13A04
C23A02
C23A04
C34A02
C34A04
Capacity kN (lbf)
1500 (335
,
000)
2000 (450,000)
3000 (660,000)
Max vertical daylight,
mm* (inches)
340 (13.4") 350 (13.8") 350 (13.8")
Horizontal daylight, mm
(inches)
265 (10.4") 340 (13.4") 370 (14.6")
Max. piston travel*, mm
(inches)
50 (2") 50 (2") 50 (2")
Platen dimensions, mm dia. 216 (8.5") dia. 216 (8.5") dia. 300 (11.8")
Platen surface hardness 55.5 HRC (600 HV) 55.5 HRC (600 HV) 55.5 HRC (600 HV)
Platens flatness toll, mm
(inches)
0.03 (0.0012") 0.03 (0.0012") 0.03 (0.0012")
Overall dimensions, mm
(inches)
810 x 425 x 1085
(31.9" x 16.7" x 42 .7")
835 x 440 x 1090
(32.9" x 17.3" x 42 .9")
805 x 450 x 1160
(31.7" x 17.7" x 4 5.7")
Weight approx., kg
305
525
755
Environmental conditions
Operating temperature
+ 10 ÷ + 40°C
Operating humidity ≤ 50%RH @ 40°C
