Manuale di Istruzione
Instruction Manual
23/08/2018 Rev.1 EN
58
4.2 MAIN MENU
The MAIN MENU is accessed after turning ON the and pressing the key twice.
Fig. 4-4
It comprises the following choices:
• TEST RUN: this is the screen used to conduct tests on specimens; it allows inputting
the specimen data, units, load rate and peak sensitivity;
• CALIBRATION: it displays the actual reading of the selected load channel and
allows accessing to the calibration table (password protected);
• ARCHIVE: access to this option is only allowed if a memory stick is plugged into the
USB port on the rear panel of the instrument; it allows scrolling among the stored
tests, download data to the PC (connected via the LAN port), printout through the
optional internal printer;
• OPTIONS: it allows setting date and time, the criteria to download data to the USB
memory stick and printout on the internal optional printer, selection of the unit to use
and erasing of the stored test data.
Use the keys to select the desired item of the MAIN MENU (it
will be highlighted by a box on the display) and confirm the selection with the
key.
The following chapters will describe in detail the different menus.
NOTE:
When the unit is installed for the first time, it is recommended to leave the unit ON for at
least 8 hours so as to fully charge the internal battery. In case it gets discharged, the clock
on the display will be zeroed.
