Controls WIZARD 2 50-C92AXX User Manual

Manuale di Istruzioni
Instruction Manual
Rev.1 EN 23/08/2018
69
4.2.4 CALIBRATION menu
This menu shows the display of the load read by the selected channel (CH1 or CH2),
either in engineering unit and in bits, and allows activating the editing of the calibration
(password protected).
Fig. 4-18
This function allows the checking of the calibration of the unit by comparing the
load/displacement indicated by the display with a reference load/displacement indicator
to check linearity and repeatability. When this screen is accessed the value of
load/displacement of the selected channel will be shown as a small value (near zero)
which corresponds to the electronic zero of the amplified signal.
WARNING:
The CALIBRATION menu is reserved to the authorised service personnel. CONTROLS
will not be responsible for any damage caused by improper setting of these parameters.
Warranty will be void if this menu is used by unauthorised personnel.
Refer to chapter 5.2.5 for full details on the use of the CALIBRATION menu.
