Controls WIZARD 2 50-C92AXX - Replacing the Oil of the Hydraulic Circuit

Manuale di Istruzioni
Instruction Manual
Rev.1 EN 23/08/2018
107
5.2.6 Replacing the oil of the hydraulic circuit
WARNING:
To avoid direct contact with the oil of the hydraulic circuit, always wear protective gloves
while performing the checking.
Periodically the oil of the hydraulic circuit must be completely replaced.
1. Discharge the old oil via the drainage screw;
Fig. 5-28
Drainage screw
(view from below)
