Fig. 2-2 Machine with 500 kN frame, code 50-C92A1X
Ref. Description
1
Load cell
2
Upper platen with spherical seat
3
Front guard
4
Lower platen
5
Piston travel indicator
6
Control unit
7
Flow control valve
8
AC motor dual stage h
ydraulic pump
with MOTOR ON switch
9
EMERGENCY BUTTON
10
ON/OFF Hydraulic valve
11
Speed selector (rapid approach, test speed)
1
2
Oil tank
12
1
7
10
6
9
11
3
2
5
8
4
