3. Also connect the overtravel microswitch of the frame to the relevant socket on the
rear of the motor box;
Fig. 3-11
4. In case two frames are connected to the same hydraulic unit, a y-cable must be used
(e.g. Code S000.45940019);
5. Refer to chapter 4.1 for the activation of the equipment.
Connector for overtravel microswitch
