Configuration Options 33
Connector Sockets
The connectors are connected in parallel, to enable a “daisy-chain”
SCSI configuration.
There are two connector sockets identified by the SCSI icon. The
sockets are located on the SCSI connector panel on the back of the
scanner, as shown in the following diagram.
