Curtis Instruments 1351 User Manual

7 — DIAGNOSTIC AND TROUBLESHOOTING
Curtis Model 1351 – December 2018
Return to TOC
pg. 118
Flash Code Fault Name Set/Clear Conditions Fault Actions
0x41
VCL Run Time Error
Fault Type(s): 1
Set: VCL Run Time Error detected
Clear: Edit VCL application software to x this error
condition; ash the new compiled software and
matching parameter settings; Reset Controller.
Shutdown all driver output
and digital output
0x42
User 1 Fault
Fault Type(s):
OEM Denable
These user faults can be set/clear by the User/OEM in
the application-specic VCL software
These fault actions can be
dened by the User/OEM
and are implemented in the
application-specic VCL
software
0x43
User 2 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x44
User 3 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x45
User 4 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x46
User 5 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x47
User 6 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x48
User 7 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x49
User 8 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x4A
(4 x 10)
User 9 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x4B
(4 x 11)
User 10 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x4C
(4 x 12)
User 11 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x4D
(4 x 13)
User 12 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x4E
(4 x 14)
User 13 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x4F
(4 x 15)
User 14 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
0x51
User 15 Fault
Fault Type(s):
See User 1 fault (above)
See User 1 fault (above) See User 1 fault (above)
Table 24 Fault Table: The Set/Clear Conditions & Fault Actions, cont’d
