Curtis Instruments 1351 User Manual

2 — INSTALLATION SPECIFICATIONS AND WIRING
Curtis Model 1351 – December 2018
Return to TOC
pg. 10
Pin Driver Output Digital Input
Analog Input
(Range)
Special or
Dedicated Usage
Related VCL*
Function References
18 Virtual Switch 7 Analog 7 (0-20V) RTD 3
Virtual_Switch_7
Analog_7_Volts
RTD_3_R
RTD_3_OUT
CSS/1313 HHP Programmer:
Configuration\Inputs\Analog Inputs
Configuration\Inputs\RTD Input
Configuration\Inputs\Virtual Switches\VSW 7
19 Virtual Switch 8 Analog 8 (0-20V) RTD 4
Virtual_Switch_8
Analog_8_Volts
RTD_4_R
RTD_4_OUT
CSS/1313 HHP Programmer:
Configuration\Inputs\Analog Inputs
Configuration\Inputs\RTD Input
Configuration\Inputs\Virtual Switches\VSW 8
20 Virtual Switch 9 Analog 9 (0-20V) Pot Wiper
Virtual_Switch_9
Analog_9_Volts
Wiper_Position
Pot_Resistance
CSS/1313 HHP Programmer:
Configuration\Inputs\Analog Inputs
Configuration\Inputs\Virtual Switches\VSW 9
21 Virtual Switch 10 Analog 10 (0-20V) Pot High (0-10V)
Virtual_Switch_10
Analog_10_Volts
CSS/1313 HHP Programmer:
Configuration\Inputs\Analog Inputs
Configuration\Inputs\Virtual Switches\VSW 5
22 Virtual Switch 11 Analog 11 (0-20V) Analog Out
Virtual_Switch_11
Analog_Out_
Command
Analog_11_Volts
CSS/1313 HHP Programmer:
Configuration\Inputs\Analog Inputs
Configuration\Inputs\Virtual Switches\VSW 11
Configuration\Outputs\Analog Output
23 HB Driver 1
Automate_Driver( )
Put_Driver( )
Driver_11_PWM
Driver_11_Current
CSS/1313 HHP Programmer:
Configuration\Outputs\Half-Bridge Drivers
24 PWM Driver 2 Switch Input 2 Proportional
Automate_Driver( )
Put_Driver( )
Driver_2_PWM
Driver_2_Current
Switch_2
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver2
Configuration\Inputs\Switches\SW 2
Table 2 Low Current Connections, cont’d
