2 — INSTALLATION SPECIFICATIONS AND WIRING
pg. 11
Return to TOC Curtis Model 1351 – December 2018
Pin Driver Output Digital Input
Analog Input
(Range)
Special or
Dedicated Usage
Related VCL*
Function References
25 Digital Out 2 Switch Input 11
Automate_Driver( )
Put_Driver( )
Digital_Output_2_State
Switch_11
CSS/1313 HHP Programmer:
Configuration\Outputs\Digital Drivers
Configuration\Inputs\Switches
26 PWM Driver 3 Switch Input 3
Automate_Driver( )
Put_Driver( )
Driver_3_PWM
Driver_3_Current
Switch_3
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver3
Configuration\Inputs\Switches\SW 3
27 PWM Driver 4 Switch Input 4
Automate_Driver( )
Put_Driver( )
Driver_4_PWM
Driver_4_Current
Switch_4
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver4
Configuration\Inputs\Switches\SW 4
28 PWM Driver 5 Switch Input 5
Automate_Driver( )
Put_Driver( )
Driver_5_PWM
Driver_5_Current
Switch_5
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver5
Configuration\Inputs\Switches\SW 5
29 PWM Driver 6 Switch Input 6
Automate_Driver( )
Put_Driver( )
Driver_6_PWM
Driver_6_Current
Switch_6
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver6
Configuration\Inputs\Switches\SW 6
30 PWM Driver 7 Switch Input 7
Automate_Driver( )
Put_Driver( )
Driver_7_PWM
Driver_7_Current
Switch_7
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver7
Configuration\Inputs\Switches\SW 7
31 PWM Driver 8 Switch Input 8
Automate_Driver( )
Put_Driver( )
Driver_8_PWM
Driver_8_Current
Switch_8
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver8
Configuration\Inputs\Switches\SW 8
32 PWM Driver 9 Switch Input 9
Automate_Driver( )
Put_Driver( )
Driver_9_PWM
Driver_9_Current
Switch_9
CSS/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver9
Configuration\Inputs\Switches\SW 9
Table 2 Low Current Connections, cont’d
