PRINT WIDTH Width of printing area:
20 mm 34 mm 48 mm 62 mm 76 mm
22 mm 36 mm 50 mm 64 mm 78 mm
24 mm 38 mm 52 mm 66 mm 80 mm
26 mm 40 mm 54 mm 68 mm 82 mm
D
28 mm 42 mm 56 mm 70 mm
30 mm 44 mm 58 mm 72 mm
32 mm 46 mm 60 mm 74 mm
PAPER THRESHOLD Threshold value (in percent) for the recognition of paper presence by the paper presence
sensor:
30% 40%
D
50%
60% 70% 80%
90%
NOTCH/B.MARK
POSITION
Position of the alignment notch and choice of appropriate notch sensor:
Disabled
D
= the notch alignment is not performed
Transparence = the notch position is detected by both the sensors (transparence)
NOTCH/B.MARK
THRESHOLD
Threshold value (in percent) for the recognition of notch presence by notch sensor:
30% 40% 50%
60%
D
70% 80%
90%
NOTE: If the “Notch/B.Mark Position” parameter is disabled, this parameter is not printed.
NOTCH DISTANCE “Notch Distance” is the minimum distance (in mm) between the upper edge of ticket and
the notch (see chapter 11).
The numeric value of distance is made up with the following four parameters for the setting
of three digits (two for the integer part of number and one for the decimal part) and of sign:
NOTCH DISTANCE SIGN Sign setting:
+
D
= positive distance
- = negative distance
NOTCH DISTANCE [mm x 10] Setting the digit for tens:
0
D
2 4 6 8
1 3 5 7 9
NOTCH DISTANCE [mm x 1] Setting the digit for units:
0
D
2 4 6 8
1 3 5 7 9
93
