CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
7 - 4
DC Motor Driver - Conveyor, Wrap Belt and Product Separator Wheel
Item Function Item Function
AC+ AC 110V+ STOP Brake/Stop
AC- AC110V - GND Brake/Stop
M+ DC Motor output, +(positive), voltage:
0~130V
F1 3A 20mm fuse
M - DC Motor output, -(negative), voltage:
0~130V
MV Max voltage: Max. voltage limitation
VIN Control Voltage 0~4.65V FV Torque Adjustment
GND Control Voltage 0~4.65V
M+
M-
M+ YEL
M- (WHT)
AC+ (BLK)
AC- (RED)
AC+
AC -
F1
MV
GND (PUR)
Power supply
indicator ○
3
GND (ORG)
VIN (BRN)
STOP
(
GRN
)
5V
VIN
STOP
GND
U7
Power supply
indicator ○
1
Power supply
indicator ○
2
GND
FV
MV
U7
