CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
7 - 5
Note: All the LED indicators should be ON when power is ON (D11 red LED is flashing or ON).
The standard operation procedures of MV are below:
a. Speed adjustment:
Conveyor speed: Press product speed twice, set the value at 255 (max) and then press ENTER
key.
Wrap belt motor speed: Press product speed three times, and set the value at 255 (max).
Separator motor speed: Press key twice, and set the value at 255 (max).
b. Set the voltmeter at “DCV” mode.
MV (Max Voltage): the positive probe (+) is connected to M+, the negative probe (–) is connected
to M-. Adjust MV, and check the voltage value with a voltmeter.
CL (Current Limit): No adjustment is required.
OL (Over current Limit): No adjustment is required.
The maximum motor voltage:
Conveyor motor at 130V
Wrap Belt motor at 130V
Separator motor at 90V
Check the following if the conveyor, wrap belt and separator motor do not work when the machine is
turned on:
a. Check if the fuse F1 is burned out. If not, use voltmeter to check input/output voltage.
b. Set voltmeter at "DCV" mode.
c. Connect the positive probe (+) to VIN (BRN) and the negative probe (–) to GND (ORG). And then
check if the input voltage is normal. If so, continue to check the output voltage by testing M+ and
M-.
d. Replace a new DC motor driver if output voltage is not in good condition.
