8.1.1 BPG 100
Parameter Unit BPG 100
Tube height mm 500 750 950
Column inner diameter mm 100
Cross sectional area cm
2
78.5
Max column volume l 3.2 5.2 6.2
Max column volume with extension l 6.2 8.2 9.7
Min bed height cm 1 26 46
Bed height
1
cm 26 42 55
Bed height with extension
2
cm 35 56 74
Bed height with extension
3
cm 45 67 N/A
Min bed volume l 0.3 2.0 3.6
Bed volume
1
l 2.0 3.2 4.3
Bed volume with extension
2
l 2.7 4.3 5.8
Bed volume with extension
3
l 3.5 5.2 N/A
Max pressure
4
bar(g) 8
Total weight (tare mass) kg 15 16 17
Total weight (tare mass) with extension kg 21 22 23
Adapter weight kg 7
Overall dimension D×W×H cm 48×48×127 48×48×152 48×48×172
Height with extension tube cm 165 190 210
Operating temperature °C 4 to 40
1
W
ithout an extension tube.
2
These bed heights and volumes are achievable using a packing extension during consolidation of the bed (sedimen-
tation). Total amount of 75% slurry must fit into column + extension with adapter.
3
The bed height and volume are achievable when retaining the extension tube during the final packing step. Adapter
must seal at least 5 cm into the column tube to avoid high tensions on glass tube.
4
Use a pressure gauge to monitor the pressure.
8 Reference information
8
.1 Specifications
8.1.1 BPG 100
BPG Columns Operating Instructions 29193223 AB 127
