3.1 Overview
I
ntroduction
The BPG column can be used conjunction with a BioProcess system or as a stand-alone
unit connected to a pump. There are five sizes of the BPG columns.
The BPG columns are listed in the table below with the internal diameters, specific
d
esign pressure and the various heights.
Characteristics BPG 100 BPG 140 BPG 200 BPG 300 BPG 450
Internal diameter
(
mm)
100 140 200 296 446
Design pressure
(
bar)
8 6 6 4 2.5
Column height
(
mm)
500, 750 ,
950
500, 750 ,
950
500, 750 ,
950
500, 750 ,
950
500, 750 ,
1000
For detailed specifications of the BPG columns, refer to C
olumn specifications, on page
125.
All BPG columns are equipped with wheels with brakes, except the BPG 100 column, for
which wheel with brakes are an option.
3 Column descriptions
3
.1 Overview
BPG Columns Operating Instructions 29193223 AB 19
